Description
***EMAIL FOR AVAILABILITY***
25G Cloud Gateway with 500+ UniFi device / 5,000+ client support, 12.5 Gbps IPS routing, and complete high availability.
Overview
Dimensions
442.4 x 43.7 x 325 mm
(17.4 x 1.7 x 12.8")
(17.4 x 1.7 x 12.8")
UniFi Application Suite
Network
Yes
Managed UniFi Devices
500+
Simultaneous Users Connected
5,000+
Default WAN Ports
(1) 25G SFP28
(1) 2.5 GbE RJ45
(1) 2.5 GbE RJ45
LAN Ports
(1) 25G SFP28
(2) 10G SFP+
(1) 2.5 GbE RJ45
(2) 10G SFP+
(1) 2.5 GbE RJ45
IDS/IPS Throughput
12.5 Gbps
Form Factor
Rack Mount (1U)
Redundancy
Shadow Mode HA
(2) Hot-Swappable PSUs
(2) Hot-Swappable PSUs
Capacity
SSL/TLS Inspection Concurrent Sessions
10,000
Concurrent Sessions
1 Million
New Sessions / Second
71,000
Security
Stateful Firewall
Yes
Application-Aware Layer 7 Firewall
Yes
SSL Inspection & URL Filtering
Yes
DPI & Traffic Identification
Yes
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
Yes
Content Filtering
Yes
Intrusion Prevention (IPS/IDS)
Yes
Ad Blocking
Yes
IDS/IPS Signatures
95,000+
with CyberSecure Enterprise
with CyberSecure Enterprise
VLAN/subnet-based traffic segmentation
Yes
VPN & SD-WAN
License-Free SD-WAN
Yes
Site-to-Site VPN
Site Magic
Yes
IPsec
Yes
OpenVPN
Yes
VPN Server
Identity Endpoint One-Click VPN
Yes
Teleport Zero-Configuration VPN
Yes
WireGuard
Yes
OpenVPN
Yes
L2TP
Yes
VPN Client
OpenVPN
Yes
WireGuard
Yes
VPN Server Single User Throughput
Identity Endpoint One-Click VPN
1.2 Gbps
Teleport
1.2 Gbps
WireGuard
1.2 Gbps
OpenVPN
210 Mbps
L2TP
280 Mbps
Site-to-Site VPN Single Tunnel Throughput
Site Magic
1.1 Gbps
OpenVPN
120 Mbps
IPsec
580 Mbps
VPN Client Single Tunnel Throughput
WireGuard
980 Mbps
OpenVPN
180 Mbps
Networking
Multi-WAN Load Balancing
Yes
Shadow Mode (VRRP) High Availability
Yes
Dynamic Routing
OSPF
Yes
BGP
Yes
Multicast DNS (mDNS)
Yes
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
Yes
Integrated RADIUS Server
Yes
RADIUS over TLS (RadSec)
Yes
Additional Internet Failover with LTE Backup
Yes
Internet Quality and Outage Reporting
Yes
Policy-based WAN and VPN routing
Yes
Customizable DHCP server
Yes
IPv6 ISP support
Yes
IGMP proxy
Yes
Hardware
Max. Power Consumption
82W
Power Method
Universal AC input, 100-240V AC, 7A Max., 50/60 Hz
Power Supply
(2) Hot-swappable 150W CRPS
Supported Voltage Range
100—240V AC
Processor
18-core ARM® v8.2 at 2 GHz
System Memory
16 GB
Weight
6.5 kg (14.3 lb)
Enclosure Material
Aluminium CNC, SGCC steel
LCM Display
1.3" Touchscreen
Management
Ethernet
Bluetooth
Bluetooth
Ambient Operating Temperature
0 to 40° C (22 to 104° F)
LEDs
Ethernet
Yes
SFP+
Yes
ESD/EMP Protection
Air: ± 8kV, contact: ± 4kV
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Button
Factory Reset
Software
Application Requirements
Mobile app
UniFi iOS™:Version 10.16.2 and later
UniFi Android™: Version 10.17.2 and later
UniFi Android™: Version 10.17.2 and later
