Description
Category 6 Ethernet cable for high-speed deployments located in environments that require plenum-rated cabling
The U-Cable-C6-CMP is a Category 6 UTP cable that supports speeds up to 1Gbps with its 23 AWG solid copper, twisted pair conductor. The conductor's small diameter, combined with the cable's anti-crosstalk divider, isolates and protects signals from interference. The U-Cable-C6 is also a CMP cable with a fire-resistant jacket that ensures full fire prevention, which is especially critical in plenum spaces where air is circulated to facilitate building HVAC. Category 6 Ethernet connectors are recommended to accommodate the conductor's size and optimize its performance.
- Category 6 Unshielded Twisted Pair (UTP) cable
- Communications Multipurpose Cable, Plenum (CMP)-rated, fire-resistant jacket
- 1,000 ft (305 m)
- 23 AWG solid copper conductor pair
- Anti-crosstalk divider
- For 1000BASE-T Ethernet applications
- Data Transfer Rate : 1 Gbit/s
- Cable Type : Category 6
- Connector on First End Details : Bare Wire
- Environmentally Friendly : Yes
- Jacket Material : Low Smoke Fire Resistant Polyvinyl Chloride (LS FR-PVC)
- Product Color : White
- Shielding : No
- Device Supported : Network Device
- Connector on Second End Details : Bare Wire
- Manufacturer Website Address : http://www.ui.com
- Connector Type on First End : Bare Wire
- Connector Type on Second End : Bare Wire
- Product Type : Network Cable
- Manufacturer : Ubiquiti Inc.
- Cable Length : 1000 ft
- Jacket Type : CMP,Plenum
- Features : Crosstalk Protection,Interference Protection,Fire Resistant,Flame Retardant
- Product Line : Unifi
- American Wire Gauge : 23 AWG
