Description
Build and expand your network with the UniFi ® Switch, part of the Ubiquiti Networks ® UniFi Enterprise System. The UniFi Switch, model USW-Aggregation-Pro, is a congurable 10G ber Layer-3 switch. It offers 28 10G SFP+ ber links to your devices and 4 25G SFP28 ber uplink options to your enterprise network.
The USW-Aggregation-Pro features a 1.3" touch LCM. The LCM provides current switch states and the necessary information you need for quick diagnosis.
Managed and congured by the UniFi Network Application with UniFi Network Mobile app support, the UniFi Switch offers an extensive suite of advanced Layer-3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port, Inter-VLAN routing, static routing, and DHCP server. The UniFi Network Application and mobile app allow admins to congure and monitor virtually all of the switch features in a graphical user interface from anywhere.
RPS DC inputis a new feature on USW-Aggregation-Pro, this DC input provides redundant power when the switch is connected to USP-RPS (UniFi Smart Power RPS) via RPS DC input. When the switch's internal PSU is off, the Switch function can keep working by backup power from the USP-RPS input port.
The USW-Aggregation-Pro features a 1.3" touch LCM. The LCM provides current switch states and the necessary information you need for quick diagnosis.
Managed and congured by the UniFi Network Application with UniFi Network Mobile app support, the UniFi Switch offers an extensive suite of advanced Layer-3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port, Inter-VLAN routing, static routing, and DHCP server. The UniFi Network Application and mobile app allow admins to congure and monitor virtually all of the switch features in a graphical user interface from anywhere.
RPS DC inputis a new feature on USW-Aggregation-Pro, this DC input provides redundant power when the switch is connected to USP-RPS (UniFi Smart Power RPS) via RPS DC input. When the switch's internal PSU is off, the Switch function can keep working by backup power from the USP-RPS input port.
- Layer 3 Switch provides reliable, efficient connectivity to ensure maximum feasibility
- Lets you conveniently connect different networks to enable improved flexibility to your infrastructure
- Power Supply power source for dependable power supply
- Supports layer 3 switching for enhanced performance and usability
- Rack mounting enables you to organize wires & secure cables for professional installation
- Management capability allows maximum efficiency and with unrestricted control
- Lets you conveniently connect to the 10 gigabit ethernet Ethernet technology to offer maximum productivity
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Redundant Power Supply Supported : Yes
- Ethernet Technology : 10 Gigabit Ethernet,25 Gigabit Ethernet
- Power Source : Power Supply
- Layer Supported : 3
- Port/Expansion Slot Details : 28 x 10 Gigabit Ethernet Expansion Slot,4 x 25 Gigabit Ethernet Expansion Slot
- Modular : Yes
- Form Factor : Rack-mountable
- Manufacturer Website Address : http://www.ui.com
- Uplink Port : Yes
- Product Type : Layer 3 Switch
- Number of Total Expansion Slots : 32
- Manufacturer : Ubiquiti Inc.
- Product Model : USW-Aggregation-Pro
- Power Consumption : 100 W
- Manageable : Yes
- Media Type Supported : Optical Fiber
- Network Technology : 10GBase-X,25GBase-X
- Product Line : Unifi
- Expansion Slot Type : SFP+,SFP28
- Number of SFP+ Slots : 28
